/ Description
LEDBARIIIT24 is a High-Output, 500 lumens/foot linear LED fixture. Built to size up to 24." LEDBARIII24 spreads light at a 90° angle, and is an excellent linear lighting solution for showcases, displays, closets, bathrooms, and kitchens. LEDBARIII uses a double-row 3528 240/m Commercial Grade LED Strip. Our linear LED fixtures are turn-key, bespoke, linear lighting solution, therefore allow 5-10 business days for fabrication. For rush orders, or customized configurations contact-us at: 1-800-679-4902 | M-F | 9AM-5PM | EST or email us: sales@GlowbackLED.com
LEDBARIIIU24: High Output Showcase Lighting | 90° Light Spread
Please ensure you enter your desired size
up to 1000 lumens (500 lumens/ft) Squared Lens, Alternative to Quarter-Circle Rounded Lens Available any size up to 24" 8ft of wire and our smart-connectors included with every bar Connect multiple bars to one Power Supply Dimmable DOTLESS Fixture (w/ frosted Lens) Commercial Grade LED's High Output LED Lighting! Clipless-Installation Uses Smart, High-Output Connectors TURN KEY Linear Lighting Solution: Built to your specs High Color Rendering (>90) 1 Watt - 12 Watts (0.25 A- 1.00A) 50,000+ hour lifetime 3-Year Limited Warranty
LEDBARIIIT24 is designed with showcase and display builders in mind. It is a high output (500 lumens/foot) linear LED fixture with a focused 90° degree light spread. In addition to being an excellent linear lighting solution for displays and showcases, it can be used in closets, bathrooms, kitchens, garages, museum cases, and more. Its high light output makes it an ideal linear LED task-lighting solution.
Installation
Clip-less Installation System. Install in minutes by screwing through pre-fabricated holes into mounting surface. Achieves a clean and trimless installation look.
Connections:
Use of Smart, High-Output Connectors and Cable-Distribution systems. Connect multiple LED bars to one Power Supply using the following guide.
GlowbackLED™ Commercial Grade Linear LED Fixture/Bar Advantage
- Quality: Commercial Grade Linear LED Fixtures are built to order with top-quality, commercial grade components. Our linear LED bars are built by professionals for professionals for quality linear LED lighting solutions.
- Dependability: Commercial Grade linear LED fixtures are built with top-quality, lasting components. Our line of LEDBAR's are designed to last 50,000 until they've dimmed to 70% of their original brightness.
- Color Rendering: High Color Rendering (>90) means your space and objects show their true vivid colors. Inexpensive LED alternatives will dull the appearance of objects they illuminate.
- Efficiency: Our Commercial Grade Linear LED strips boast industry leading efficiency. Delivering 85 lumens/Watt
- Safety: Our Commercial Grade linear LED fixtures are built with tested high quality components for optimal thermal control and electrical over-stress protection. All Commercial Grade Linear LED fixtures/bars are Class-2 compliant.
- Turn-Key Solution: GlowbackLED™ specializes in customized lighting solutions. We have the biggest selection of commercial, architectural, and specification grade LED strips on the market. We manufacture lighting products to your specs, for a bespoke LED lighting solution Contact-Us: sales@glowbackLED.com or 1-800-679-4902 | M-F | 9AM-5PM EST
/Features
Dimmable and Nondimmable Power Supplies
/Product Specs
Model # | LEDBARIIIXX (up to 24") |
Manufacturer | GlowbackLED™ |
Lamp Source | LED |
LED Type | Commercial Grade 3528 240/M |
Input Voltage | 12VDC |
Power Output | 1 Watt (0.25 A) - 12 Watts (1.00 A) |
Lumen Output | 500 lumens/foot (Clear Lens) |
Efficiency | 85 lumens/watt |
Color Rendering | CRI > 90 |
Color Temperature | 3000K (Warm) 4500K (Natural White) 6500K (Bright White) |
Mount Type | ClipLess Installation, Use-Pre Fabricarted holes (#6 screw) |
Connection Type | Smart High-Output Connectors. See Guide Connect Multiple Bars to one Power Source |
Dimming | TRIAC (Phase-Dimmable) 0-10V DALI DMX |
Warranty | 50,000+ LED Lifetime |
Returns | No Returns or Exchanges on Built-to-Size Linear LED Fixtures |
><inline><inline><b style: |
font-size: 18px
|
>500 lumens/foot</b><br /><inline style: |
font-size: 14px
|
>LED bar up to 24<br /></inline><b><i><inline style: |
"font-size: 14px
|
/Applications
Slim-Low Profile Surface Mounted Linear LED Fixture
- High-Output Under Cabinet Linear LED Lighting
- High Output Super Bright LED Over Cabinet Lighting
- High Output Super Bright Linear LED Strip Lighting
- High Output Linear LED Fixtures for Garages and Task LED Lighting
- High Output Linear Task LED lighting
- Super Bright LED Kitchen Cabinet Lighting
- Super Bright Linear LED closet Lighting
- Ultra-Bright Linear LED Museum Lighting
- Architectural Grade High-Output Linear LED Fixture
- Ultra Bright, high Color Rendering Showcase Lighting
- Super Bright Showcase Linear LED lighting
- Ultra bright Jewelry Retail Linear LED Lighting
- High Output Linear LED Lighting for Garages
- High Output Workshop and Shop Linear LED lighting
- LED Task Lighting Ultra Bright
- Super Bright Restaurant Task Lighting
- Linear LED task lighting for Hotels and Hospitality Installations
- High Output Super Bright Bathroom Lighting
