/ Description
Features
- Ultra Bright! up to 3,200 lumens! (400 lumens/foot)
- Configured for simple and head-ache free plug-and-play installation.
- Designed to easily conceal under cabinets, inside display cases, and more.
- Tailored Look and Feel Built any size 84" - 94"
- UL-Listed
LED Bar Installation Instructions
Options
Housing Type
- Choose the fixture type best suited to your applications. High Output Corner mounted fixtures feature a clipless direct screw mounting system.
Color Temperature
- Available in 3000K, 4500K, and 6500K
- Click here for our Color Temperature Selection Guide
Size
- Built to any size 84" - 94"
Powering
- These slim LED fixtures require a remote power-supply or LED Driver to operate. For help selecting a power supply, click here for our Power Supply Selection Guide. Use one of our pre-configured
plug-and-play Dimmable Power Supplies with multiple inputs:
Any Size 84" - 94"
48 Watts
3,400 Lumens
These high-output LED bars provide up to 400 lumens/foot and are an excellent light source for retail and display case lighting applications. Built any size 84" - 94" and available in in a variety of configurations. This LED Bar is great for closets, high-output under cabinet lighting, jewelry displays, and more.
- Light Output: up to 3,000 lumens (400 lumens/foot)
- Voltage: 24VDC (Standard)
- Wattage: up to 48 Watts (6 Watts/foot)
- Size: Any size 84" - 94"
- Warranty: 5-Year Limited Warranty
- Safety: UL-Listed
/Product Specs
| Dimensions | U: Any size 84" - 94" L x 1.17" W x 1.17" H |
| Input Voltage | 24VDC (Standard) |
| Wire Lead | 8ft 20-2 Wire w/ Connector for more information click here: Power Supply Selection Guide |
| Driver | Requires Remote Driver. Dimmable, Non-Dimmable, and Custom Configurations Available |
| Power | up to 48 Watts (6 Watts/foot) |
| Light Output | up to 3,400 lumens (400 lumens/foot) determined at 6500K with a frosted lens |
| Color Temperatures | 3000K 4500K 6500K custom color temperatures available upon request |
| Lifetime | Rated for up to 50,000 hours of useful life |
| Warranty | 5-Year Limited Warranty |
| Safety | UL-Listed Class-2 Listed for Damp Location |
>
<img src: |
/content/v/vspfiles/images/UL Mark Final.jpg" />
Any Size 84" - 94" 48 Watts 3,400 Lumens |
/Applications
Slim-Low Profile Surface Mounted Linear LED Fixture
- LED Cabinet Lighting
- LED Under Cabinet Lighting
- LED Over Cabinet Lighting
- LED In Cabinet Strip Lighting
- LED Under Cabinet Linear Lighting
- LED Over Cabinet Linear Strip Lighting
- LED Shelf Lighting
- LED Shelving Lighting
- LED Linear under Shelf Strip Lighting
- LED Linear Over Shelf Strip Lighting
- Professional Linear LED Strip Lighting
- Class-2 Linear LED Strip Lighting
- Hospitality Linear LED Strip Lighting
- Restaurant Linear LED Lighting
- Restaurant Under Bar Linear Task Lighting
- Restaurant Server Station Linear Task Lighting
- Restaurant Kitchen Linear Task Lighting
- LED Linear Hotel Lighting
- Residential Cove Lighting
- Linear Cove Lighting
- Linear Commercial Strip Cove Lighting
- Good Color Rendering Linear LED Cove Lighting
- LED Strip Lighting for Bars
- LED Linear Lighting for Hotel Cove Lighting
- Linear LED Strip Lighting for Office Task Lighting
